Product Description
The Filter Press is a kind of the solid-liquid separation machinery. It has been widely used in industrial production for many years. It has a good solid-liquid separation effect and wide suitability,especially for separation of fine and sticky materials. It has its special advantages.
When the mixed liquid flows through the filter cloth,the solid will be trapped on the filter cloth and accumulated to form into the cake. The clean liquid,which has not included the solid, will permeate from the filter cloth and be discharged from the taps on the plates or from the pipes on the 4 corners.
Product Details
Character Of Chamber Filter Press
1.Stable performance
2.High automation
3.Safe and reliable
4.Easy to operate
5.Backwashing can be realized
Application
It is suitable for concentrate filtration and dry discharge of tailings, the particle size can be up to 500 meshes.
Technical Parameter
| Filtration Area (M2) | Qty of Plate (PCS) | Plate Size (mm) | Power (KW) | Weight (KGS) |
| 200 | 51 | 1500X1500 | 7.5 | 18300 |
| 300 | 76 | 1500X1500 | 7.5 | 24130 |
| 350 | 88 | 1500X1500 | 7.5 | 27200 |
| 400 | 101 | 1500X1500 | 7.5 | 30100 |
| 500 | 125 | 1500X1500 | 7.5 | 36250 |
